Description
Additional Features:
- Frequency range: 10 MHz-6 GHz
- Measurement Speed: 150 μsec/point
- Dynamic Range: 125 dB
- Source Power: +10 dBm
- Receiver Noise as Low as –115 dBm
- S-Parameter Uncertainty: < 0.05 dB
- Mixed Mode S-Parameters
- Embedding/De-embedding
- Arbitrary Impedance
- AutoCal® Simplifies 2,3 and 4-Port Calibrations
- N-type, 3.5 mm, or GPC-7 Connectors
- Sequences Automate Repetitive Keystrokes
- Enhanced Markers Simplify Data Collection
- Overlay Displays to Customize Data Viewing
- External SCSI Interface for Massive Storage
See the True Performance of Your:
- Antennas, Isolators, Filters, Duplexers, Couplers
- SAW Filters, Baluns
- Amplifiers
- Mixers
- Power Amplifiers
- Tower Mount Amplifiers
- Multiport Components
The foundation of the Scorpion® MS4623A Vector Network Measurement System (VNMS) is a high performance 2-port Sparameter measurement engine consisting of a single flexible source and ultra-linear receiver. This vector network analyzer (VNA) engine provides all the necessary features to thoroughly characterize your RF components versus time, frequency and power. Simply upgrade your Scorpion, as shown in the following table, to further apply this powerful engine towards performing 3 and 4-Port S-parameter measurements.
