Description
Additional Features:
- Frequency Range: 100 kHz to 1 GHz
- Circuit probing to facilitate the design process
- Easy programming for ATS’s
- Narrowband measurement capability for high sensitivity applications
- Provides a fully automatic tuned receiver that makes RF voltage and phase measurements easy
- Measures the phase difference between its two input channels with at least 0.1 degree resolution over a full +180 to -180 degree range
The Agilent 8508A vector voltmeter is a fully automatic tuned receiver that makes RF voltage and phase measurements easy. Its narrowband measuring technique gives a dynamic range of over 90 dB and a sensitivity of 10 micro V to trace even the smallest signal. This vector voltmeter also measures the phase difference between its two input channels with at least 0.1 degree resolution over a full +180 to -180 degree range, so they can be used for another complete set of measurements – such as electrical length, phase distortion, or impedance.
