Agilent 8165A Used Function Generator – Reliable Waveform Production

Description

Additional Features:

• Frequency range: 0.0001 Hz to 50 MHz
• Pulse/ramp (20, 80% symmetry): 1.000 mHz to 19.99 MHz
• Accuracy: ±0.001%
• Outputs are provided in programmable sine, triangle, pulse, ramp and square waveform
• Voltage ranges from: 10.0 mV p-p to 10.0 V p-p and 2.00 V p-p to 20.0 V p-p.
• Fully programmable via the front-panel or HP-IB interface
• Pulse/function capability
• Sine, triangle, and square to 50 MHz
• Pulse and ramps to 20 MHz
• Trigger, gate, and counted burst
• Synthesizer stability, precision amplitude
• Storage of operating parameters

The Agilent 8165A Programmable Signal Source is a versatile function generator with good accuracy and many trigger features. Microprocessor control assures rapid, accurate setup whether you’re programming locally or via HP-IB.

Ten complete sets of operating information can be stored and recalled. In the event of power failure, battery back-up retains all data plus the active settings.

Stable frequency is ensured with an internal crystal. The four-digit frequency display provides a 1 µHz resolution in the 1 to 9.999 mHz range. In Normal mode, the accuracy is 0.001% with a stability of ±1 X 10-6.
