Agilent 66319B Used DC Power Supply

Description

Additional Features:

• Voltage: 15V
• Current: 3A
• Power: 90W
• Programmable output resistance (-0.04 Ohm to 1 Ohm)
• Improved transient response <20 us
• Very low transient voltage drop <30 mV
• Programmable output response compensation
• Stable output for either long or short load leads
• Improved standby current measurement accuracy (New ±1A range)
• Simulate internal battery resistance of Ni-Cad, Ni-mh, Li-Ion, Li-Polymer batteries
• Negative resistance programming provides load lead voltage drop compensation from the wiring between the test fixture and actual wireless device
• 5 A peak current sourcing for next generation data transmission formats
• Programmable output response compensation to insure stable output operation for either long or short wiring
• Precision uA, mA, Amp measurement for “sleep mode,” “standby mode” and “talk mode” battery current draw characterization

The Agilent 66319B dual output mobile communications DC source provides two outputs for testing both the main battery power and the battery charger circuitry, allowing customers to test phones and chargers with the same equipment. This feature helps save on rack space (2 outputs in a ½ rack box) and eliminates the need for two separate power supplies. Excellent voltage transient response ensures maximum test-system throughput by minimizing device shutdowns due to significant voltage drops in the test wiring.
