Agilent 54615B Used Digital Oscilloscope – 100 MHz, Color Display

Description

Additional Features:

• Bandwidth: 500 MHz analog
• 1 GSample/sec simultaneously on 2 channels
• Record Length: 5 kpts
• 1 ns peak detect
• Optional expansion modules for FFT, waveform storage, and remote control
• Sweep speeds from 1 ns/div to 5 s/div

With the 54615B you can capture narrow glitches and subtle details of your signal. This 2-channel scope combines 500 MHz bandwidth, 1 GSa/s sample rate and 1 nanosecond peak detection on both channels. The 54615B peak detection allows the scope to maintain the 1 GSa/s sample rate at all sweep speeds. A horizontal accuracy of 0.005% means you can make critical timing measurements with confidence.
