Agilent 34934A Multiplexer Module – Refurbished & Tested

Description

Features:

• Quad 4×32 reed matrix
• Single-wire configuration
• High density matrix with automatic surge protection and row disconnect for flexible measurements
• Configured as a single-wire matrix, increasing the number of channels
• 100 ohm input protection resistors to limit current and protect the reed relays
• High-density configuration block
• 4×128, 8×64 or 16×32 1-wire configurations
• 4×64 or 8×32 2-wire configurations
• 100V, 0.5A switch/carry current

The 34934A also has in-rush protection resistors, but also has an automatic bypass switch for flexibility in making low-level measurements. Row disconnect switches also reduce the capacitance loading when combining modules to create larger matrices. Multiple matrix modules can be combined through the analog bus or the row expansion kit to create a larger matrix.
