Agilent 16085B Capacitance Test Fixture – Bench-Verified

Description

Additional Features:

• Measurement Instrument: Agilent HP 4194A, Agilent HP 4263B, Agilent HP 4278A, Agilent HP 4279A, Agilent HP 4284A, Agilent HP 4285A
• Frequency: DC to 40 MHz, DC Bias: -40V to +40V
• Operating Temperature: 0 to 55°C (same as for measurement instrument)

The Agilent HP 16085B terminal adapter converts the terminal configuration of the 4-terminal pair LCR meters and impedance analyzers into a 7mm terminal configuration. This means that instruments that do not have a 7mm terminal connector can use test fixures with a 7 mm terminal connector.
