Agilent 1144A Active Probe – Verified Working Condition

Description

Additional Features:

• DC to 800 MHz probe bandwidth
• 10X attenuation
• ±40 VDC + peak AC maximum input voltage

This combination is superior to that of passive divider probes because it provides minimal circuit loading at high and low frequencies. As signal speeds increase, passive divider probes may not deliver the performance needed. This can result in waveshapes that do not represent the actual signal. To help you minimize circuit loading, the Agilent 1144A boasts a 800 MHz bandwidth, 1 M Ohm input resistance, and 2 pF input capacitance. It can be connected to any instrument with 50 Ohm inputs. An external 50 Ohm termination can also be used with high impedance inputs. Provides an excellent combination of high bandwidth, high input resistance, and low input capacitance.
