Description
Additional Features:
- 3.6 GHz Network Analyzer
- Measures the reflection and transmission characteristics by incorporating the bridge
- High-precision and high-resolution measurement 35dB or more (20 MHz – Integrates the synthesizer with 1 Hz resolution
- Provides outstanding dynamic precision and resolution
- Amplitude measurement accuracy : 0.05dB
- Resolution: 0.001 dB
- Phase measurement accuracy: 0.3°
- Resolution: 0.01°
- Provided with an error correcting function (at reflection measurement)
The Advantest R3763A network analyzer is an instrument which measures the complex transmission and reflection characteristics of two-port devices in the frequency domain. It does this by sampling the incident signal, separating the transmitted and reflected waves, and then performing ratios that are directly related to the reflection and transmission coefficients of the two-port. Frequency is swept to rapidly obtain amplitude and phase information over a band of frequencies of interest.
