Advantest R3753A Network Analyzer – High-Speed Microwave Platform

Description

Additional Features:

• High throughput
• 0.1ms/point high-speed frequency sweeping and 5ms short blanking time when two-channel/ four-trace (ampliude/phase) and RBW 10 kHz
• 0.1ms/point high-speed level sweeping, high speed and long life using semiconductor switches
• Wide dynamic range
• With automatic switching on inpit attenuator, 115dB wide dynamic range, high speed and long life using semiconductor switches for switching input attenuator
• Program sweeping function
• For each segment, allows setting of frequency, output level, input attenuator,RBW, and settling time
• Signal Source
• The range of signal output is 5 Hz to 500 MHz and the range output power is 21dBm to -63dBm

The Advantest R3753A is a 500 MHz vector network analyzer. Since the analyzer employs semiconductor switches for changing the output level and for switching the input attenuator, it allows the optimum high-speed level sweeping for the drive level test of the oscillator. With the built-in BASIC controller, a high-speed ATE system can be easily configured with no external controller for processes from adjustment to inspection.
